Characteristics:
1. Machine can be used to produce sharp diagonal cut paper straw
2. Machine equipped with famous international brand electrical components, SIEMENS servo motor, SIEMENS PLC, SIEMENS HIM, Schneider, Omron, SMC, NSK to guarantee machine with stable performance
3. Machine build up with 304 stainless steel and all parts which touch with paper straw use food grade material
4. Machine can produce paper straw with flexible size, OD from 4mm to 12mm, length from 150mm to 260mm
5. Machine can produce with super high speed, from 1000pcs/min to 1600pcs/min
6. Machine equipped with two big stainless steel product storage tank, it’s convenient for operator to manage all production
|
machine model |
HF-CS1200 |
|
original straight paper straw length |
300-520mm |
|
short cross cut paper straw length |
150mm-260mm |
|
paper straw OD |
4mm-12mm |
|
cutting angle |
45°±5° |
|
cross cut speed |
0-800pcs/min |
|
stable production speed |
1000-1400pcs/min |
|
pneumatic component |
SMC |
|
machine structure material |
304 stainless steel |
|
PLC |
SIEMENS |
|
touch screen |
SIEMENS |
|
language |
Chinese/English |
|
electrical component |
Schneider |
|
bearing |
NSK |
|
servo motor |
SIEMENS |
|
servo driver |
SIEMENS |
|
voltage |
380V 3PHS 50HZ |
|
operation person |
1 |
|
straw storage tank |
2 units (stainless stell) |
|
total power |
2kw |
|
machine net weight |
700KG |
|
machine gross weight |
800KG |
|
machine size |
2600*1200*1850mm |
|
machine packing size |
2000*1400*1800mm |
