HF-MC150 muffin cup machine
Characteristics:
1.Machine can produce muffin cup with raw material such as anti-oil paper, silicone paper, PE coated paper, aluminium coated paper etc, 30-150gsm.
2.Machine can produce round-shape, square-shape, rectangular-shape, heart-shape creased muffin cup with different molds.
3.Machine can produce different size with different cup mold design, for overlarge size can be customized.
4.Machine structure is compacted and smart, with high efficiency, low power consumption, easy for operation and maintenance.
5.Machine has CE certificate, occupy small working space less than 1㎡.
|
Type |
HF-MC150 |
|
Position |
One Position with 1 forming mold |
|
Production Speed |
100-200pcs/min |
|
Cup Volume |
0.3-10oz |
|
Cup Top OD |
30-200mm |
|
Cup Bottom OD |
20-62mm |
|
Cup Height |
10-50mm |
|
Paper Sheet Size |
depend on the cup size |
|
Total Weight: |
300KG |
|
Overall Dimension: |
1300 x 500 x 1800 mm |
|
Working Air Source: |
Air pressure 0.1Mpa |
|
Tracking Rail |
CPC (Taiwan) |
|
Suitable Material: |
30-150gsm (PET Coated paper)（Greaseproof paper）（Silicon Paper） |
|
Total Power: |
0.7KW |
|
Electric Componentes |
DELIXI (CHINA) |
|
Pneumatic Cylinder |
AIRTAC (TAIWAN) |
|
Hybird Stepper Motor |
4 UNITS |
|
Stepper Motor Driver |
4 UNITS |
|
Power |
MEAN WELL (CHINA) |
|
PLC |
XINJIE (CHINA) |
|
HIM |
XINJIE (CHINA) |
|
Temperature Controller |
KCMD-XJ2(CHINA) |
